Sensepoint XCD Technical Manual SPXCDHMANEN Issue 15
11
Diagram 3 Sensepoint XCD Flammable, Toxic and Oxygen Sensor Cartridge
Accessories
A range of accessories are available to allow use of Sensepoint XCD in a wide variety of applications.
These including mounting brackets, maintenance tools, weather housings, flow housing, collecting cone,
duct mounting kit and sensor junction boxes.
Standard Weather Protection
The Standard Weather Protection (P/N:
SPXCDWP) is designed to protect the sensor
from changes in environmental conditions. This is
recommended to be fitted to a Sensepoint XCD
sensor for outdoor exposed applications,
(supplied with XCD kit).
The magnetic wand (P/N: SPXCDMAG) is
used as a tool to allow the user to
communicate with the Sensepoint XCD
transmitter for the purpose of configuration,
calibration and interrogating system status,
(supplied with XCD kit).
The Pipe Mounting Bracket (P/N: SPXCDMTMB)
is an optional accessory and may be used to
allow the Sensepoint XCD to be installed onto a
dedicated mounting post or existing structure at
the desired location.
The gassing cap, also known as calibration cap,
(P/N: S3KCAL) is an optional accessory to be
used in gas calibration and bump test of the
Sensepoint XCD.
