Sensepoint XCD Technical Manual
WatchDog s/w Version of XCD
Upper byte: Function
Lower byte: Instrument Mode
bit 0 Alarm 1 is active
bit 1 Alarm 2 is active
bit 0 Alarm 1 is active
bit 1 Alarm 2 is active
bit 0 ~ 4: warnings, W1 ~ W5
bit 5: reserved
bit 6 ~ 18: faults, F1 ~ F13
bit 19 ~ 31: reserved
bit 0 ~ 4: warnings, W1 ~ W5
bit 5: reserved
bit 6 ~ 18: faults, F1 ~ F13
bit 19 ~ 31: reserved
Upper Byte: Type Code: 0x25
Lower Byte: My Address
Upper Byte: Type Code: 0x25
Lower Byte: My Address: Dummy Spacer
Fault = 1100 + Number
Warning = Number as is
Alarm, fault and warning state
bit 0 Alarm 1 is active
bit 1 Alarm 2 is active
bit 2,3 for future expansion bit 4 Warning is active
bit 5 Fault is active
bit 6,7 for future expansion
Note: Latching relay setting latches Modbus values in
register 40006.
1: Normal
2: Warm Up after power on
3: Inhibit
12: Calibration
4: PPM
3: %Vol
5: %LEL
1: mg/m3v
Measuring Gas name string
1: Energized, 0: De-energized
High nibble: Alarm 2 Type
Low nibble: Alarm 1 Type
0: Disable, 1: Rising, 2: Falling
Bit 0, 1: Relay 1 Type
Bit 2, 3: Relay 2 Type
Bit 4, 5: Relay 3 Type
Bit 6 ~ 8: Relay 1 Status ~ Relay 3 Status
Bit 9 : Relay latch option
