A.3 User Configurable Parameter List
Menu
Item
Description
Set Calibration
Zero calibration level
Set zero calibration gas level
Set Calibration
Span calibration level
Set span calibration gas level
Select Sensor
Type of sensor
Type of sensor from the sensor list.
Available only for the flammable / IR sensors.
Select Gas
Type of gas
Type of gas from the sensor list.
Available only for the flammable / IR sensors.
Set Range
Measuring range
Measuring range
Configure Inhibit
Inhibit current
Inhibit current
Configure Inhibit
Inhibit timeout
Inhibit timeout
Set Password
Password
Password required for entering the Configuration mode
Set Calibration Interval
Calibration Interval
Calibration Interval
Set Alarms
Alarm 1 level
Alarm 1 level
Set Alarms
Alarm 1 rising/falling option
Alarm 1 rising/falling option
Set Alarms
Alarm 2 level
Alarm 2 level
Set Alarms
Alarm 2 rising/falling option
Alarm 2 rising/falling option
Set Relays
Relay 1 type
Type of relay 1 (Alarm 1, Alarm 2, Fault, Inhibit)
Set Relays
Relay 1 action
Type of relay 1 action (deenergize, energize)
Set Relays
Relay 2 type
Type of relay 2 (Alarm 1, Alarm 2, Fault, Inhibit)
Set Relays
Relay 2 action
Type of relay 2 action (deenergize, energize)
Set Relays
Relay 3 type
Type of relay 3 (Alarm 1, Alarm 2, Fault, Inhibit)
Set Relays
Relay 3 action
Type of relay 3 action (deenergize, energize)
Relay Operation
Relay on delay time
Relay on delay time
Relay Operation
Relay off delay time
Relay off delay time
Relay Operation
Relay latch option
Relay latch option
Set Location
Location tag
Location tag
Set Temperature Unit
Temperature unit
Temperature unit
Set Deadband
Deadband option
Deadband is included in the measuring range or not
