130 SMV 3000 Transmitter User’s Manual 1/99
11.4 Diagnostic Messages, Continued
Diagnostic Messages,
continued
Table 32 Non-Critical Status Diagnostic Message Table, Continued
SMV Status SCT Status Message SFC Display Message TDC Status Message Possible Cause What to Do
6-4 Output Mode PV1 (DP)
STATUS TAG ID.#
OUTPUT MODE PV1
OUTPUT MODE PV1
Analog transmitter is operating as a
current source for PV1 output.
Exit Output Mode:
SCT – Press “Clear Output Mode”
button on the DP OutCal tab.
SFC – Press [
OUTPUT] and [CLR]
keys.
6-5 Output Mode PV2 (SP)
STATUS TAG ID.#
OUTPUT MODE PV2
OUTPUT MODE PV2
Analog transmitter is operating as a
current source for PV2 output.
Exit Output Mode:
SCT – Press “Clear Output Mode”
button on the AP OutCal tab.
SFC – Press [
OUTPUT] and [CLR]
keys.
6-6 Output Mode PV3
(Temp)
STATUS TAG ID.#
OUTPUT MODE PV3
OUTPUT MODE PV3
Analog transmitter is operating as a
current source for PV3 output.
Exit Output Mode:
SCT – Press “Clear Output Mode”
button on the TEMP OutCal
tab.
SFC – Press [
OUTPUT] and [CLR]
keys.
6-7 Output Mode PV4 (Flow)
STATUS TAG ID.#
OUTPUT MODE PV4
OUTPUT MODE PV4
Analog transmitter is operating as a
current source for PV4 output.
Exit Output Mode:
SCT – Press “Clear Output Mode”
button on the FLOW OutCal
tab.
SFC – Press [
OUTPUT] and [CLR]
keys.
3-7 PV4 Independent
variable out of range
- STATUS 3-7
For R250 Laminar Flow transmitters
only. Asserted when a PV is not
within the range of a term in the
laminar Flow equation.
• Check the value of every PV
against the ranges in the
Laminar Flow equation.
• Redefine the equation, if
necessary.
