62
General network outputs
no_WSHPEnableValue
0
to 100
Null
B
acnet
Numeric
Output
97
This point is considered for
Network point sharing of
WSHP state through
Waterflow status
T
able 29:
General netw
ork outputs
(Continued)
Name
Range
Default
Value
BA
Cnet
P
oint Type
BACnet
Object
Instance
ID
Description
61
63
Table of Contents
default chapter
3
Table of Contents
3
Declaration
5
FCC Part 15 Compliant
5
Waste Electrical and Electronic Equipment (WEEE)
5
Important Safety Information and Installation Precautions
6
Regulation (EC) no 1907/2006
6
Chapter 1 - Introduction
9
About TC500A
9
Scope of the Document
9
Reference Documents
9
Terms, Acronyms, and Abbreviations
10
Chapter 2 - I/O Configuration
11
Terminal Input/Output
12
Terminal Configuration
13
Terminal Input Characteristics Configuration
15
Sylk Sensors
16
Space Temperature & Humidity Sensor Inputs
17
Chapter 3 - Application Configuration
19
Fan Configuration
20
Cooling Configuration
22
Heating Configuration
23
Dehumidification Configuration
25
Humidification Configuration
26
Heat Pump Configuration
27
Filter Configuration
28
Chapter 4 - Common Configuration
29
Equipment Configuration
30
Standby Configuration
30
Control Configuration
31
Multi-Sensor Configuration
32
Occupancy Setpoints Configuration
34
Recovery Setpoint Configuration
35
Demand Shift Setpoints Configuration
36
Thermostat Configurations
37
Sylk Calibration Configuration
39
Sylk Sensor Configuration
41
Alarm Configuration
42
Space Temperature Alarm Configuration
43
Chapter 5 - Configuration Points for Point Sharing
45
Configuration Points for Point Sharing
46
Chapter 6 - Network Inputs
51
User Non-Configurable Network Inputs
52
User Configurable Network Inputs
54
Sylk Sensor Proxy Inputs
56
Chapter 7 - Network Outputs
57
General Network Outputs
58
Chapter 8 - Bacnet Objects for Alarms
63
Bacnet Object Used for Alarm
64
Chapter 9 - Bacnet Guidelines for TC500A
69
Situational Bacnet Guidelines for TC500A
70
Other manuals for Honeywell TC500A
User Guide
79 pages
Mounting Instructions
6 pages
Quick Start Guide
8 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Honeywell TC500A and is the answer not in the manual?
Ask a question
Honeywell TC500A Specifications
General
Brand
Honeywell
Model
TC500A
Category
Thermostat
Language
English
Related product manuals
Honeywell TC300
124 pages
Honeywell T4
16 pages
Honeywell T6
9 pages
Honeywell T5
7 pages
Honeywell T9
36 pages
Honeywell T3
22 pages
Honeywell T5+
24 pages
Honeywell T4R
2 pages
Honeywell T3M
22 pages
Honeywell T3R
22 pages
Honeywell T87F
4 pages
Honeywell T8000
24 pages
