Touchpoint Plus User Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 100 Technical Handbook
7.14 Viewing and Exporting Event History
The event history for the complete system can be viewed in date order (latest first). The history can be filtered by
Alarm, Fault, Inhibit, or Warning.
Note: Touchpoint Plus does not adjust automatically for daylight savings time. So it will retain a backup of the earlier
data if the clock is backdated (e.g. when ending daylight savings time).
7.14.1 To View the Event History:
Touch Menu>Information>Event History, then touch the Filter icon of choice or scroll through the list.
7.14.2 To Export the Event History:
First touch the SD Card icon to ensure that you have sufficient empty space on the SD card.
Touch Menu>Information>Event History. Select the events of interest, using filters if required, and touch
Export Event.
The event history is exported to SD card: \LOG\EXPORT\EVTYYYYMMDDhhmmss.csv in CSV file format. It may be
opened by standard spreadsheet, database or text editing programs.
Some earlier versions of spreadsheet software are limited to 65,526 entries and may not show all exported events. In
this case it may be necessary to use later software.
7.15 Accessing the System Information and Service Contact Details
Touch Menu>Information>System information to view details about the Firmware, Software and serial
numbers.
Touch Menu>Information>Service Contact or see the back page of this manual for details of how to access
technical support.
7.16 System State and System Failure Relays
The Main Module has three relays (30 VDC or 250 VAC, both 1.7 A):
• One or both System State relays can activate if there is any active alarm, fault, warning or inhibit in the system (if
configured).
• The System Failure relay can activate if the safety function of the system is not operating, for example due to a
major fault or power loss.
Refer to the Ch 7.6 and Figure 19 for further information.
Note: One of either RLY1 or RLY2 in main board relay shall be configured to System inhibit Relay.
