MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 43 Technical Handbook
Module Label
Terminal
Identifier
Field device
mV In 7
19
S
Sensitive (+)
20
01
Signal
21
NS
Sensitive ( )
mV In 8
22
S
Sensitive (+)
23
01
Signal
24
NS
Sensitive ( )
Table 7. mV Input Module Connections
Catalytic Detector Connections
Touchpoint Plus
mV Input
Module
Sensor
