Commissioning
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 80 Technical Handbook
6.16.2 How to Restore the Configuration
To restore a configuration, you must first copy the stored file [Your PC] \\CFG\TPP_CFG.bin to the root
directory of an empty SD card (FAT32), and then an Administrator must follow the reverse process of backing up, i.e.
use [Import] instead of [Export].
Note: \\CFG\TPP_CFG.bin must be inside the specific folder on the SD card.
Note: Before attempting to restore from a saved configuration you must ensure that the current status is exactly the
same as it was when the backup file was exported. In other words the module installation status and commissioning
status must be exactly the same or the system will not import the configuration data.
CAUTION
Restoring the configuration does not include the gas calibration data. It could be necessary for user
to conduct the gas calibration after restoring the configuration.
