Honeywell Touchpoint Plus Technical Handbook

Technical Specifications
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 123 Technical Handbook
Chapter 11.
11.1 Environmental
Sealed enclosures are rated IP65 NEMA 4x indoor, and can be installed indoors only in a Pollution Degree 2, 10 to
95% RH Non-Condensing environment that affords total protection from rain, snow and direct sunlight.
Operating Temperature
-10°C to + 55°C
Storage Temperature
-25°C to + 60°C
Operating Humidity (closed)
10 to 90% RH (non-condensing)
11.2 User Interface and Main Module
LCD Touch Screen Type
7 TFT Colour LCD with LED Backlight (resistive touch screen)
800 x 480 pixels (WVGA) Resolution
Active area 155.08 mm (H) x 86.92 mm (V)
Front Display
Green Power LED
Red Alarm LED
Yellow Fault/inhibit LED
Alarm Mute /Reset Push Button
Alarm Buzzer (Sound Level: 70 dB at 1 m)
Communication Outputs
1) 10/100 Mbps Ethernet Interface with standard RJ-45
connector
2) RS-485 Modbus connections supporting 115.2 kbps max.
Output Relays
Two configurable and one fixed System State Relays:
1.7 A @ 250 VAC, 1.7 A @ 30 VDC (non-inductive load)
Dedicated Audio and Visual alarm
Four outputs to external devices
Supply voltage Vs (18 32 VDC) 1.8* VDC (max), max 300 mA
per channel
*Voltage drop at ambient temperature
Remote Terminals
Optional remote acknowledge, reset and inhibit
Module Power Consumption
4.4 W for User interface module and Main Module (Max 33.2W @
Audio/Visual Alarm device connected)

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
