Honeywell Touchpoint Plus Technical Handbook

MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 46 Technical Handbook
5.2.14 Relay Output Module Connections
Module Label
Terminal
Identifier
Field Device (max)
RLY 1
1
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
2
COM
3
NO
RLY 2
4
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
5
COM
6
NO
RLY 3
7
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
8
COM
9
NO
RLY 4
10
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
11
COM
12
NO
RLY 5
13
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
14
COM
15
NO
RLY 6
16
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
17
COM
18
NO
RLY 7
19
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
20
COM
21
NO
RLY 8
22
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
23
COM
24
NO
RLY 9
25
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
26
COM
27
NO
RLY 10
28
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
29
COM
30
NO
RLY 11
31
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
32
COM
33
NO
RLY 12
34
NC
1.7 A @ 250 VAC
1.7 A @ 30 VDC
35
COM
36
NO
Table 11. Relay Output Module Connections

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
