Honeywell Touchpoint Plus Technical Handbook

Event Codes
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 147 Technical Handbook
Chapter 18.
Event
Type
Code
Long Description
Triggered
Display in Event
History
Details
Alarm
1
Alarm1 occurred
Main Board
Alarm1 occurred
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
2
Alarm2 occurred
Main Board
Alarm1 occurred
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
3
Alarm3 occurred
Main Board
Alarm1 occurred
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
4
Alarm1 cleared
Main Board
Alarm1 cleared
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
5
Alarm2 cleared
Main Board
Alarm1 cleared
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
6
Alarm3 cleared
Main Board
Alarm1 cleared
CH: xx, Type: xx,
xxx[unit]
Type
Threshold/STEL/TWA,
value
Alarm
7
Reset all alarms by user
Main Board
Reset all alarms
Fault
1
Internal communication fault
All
Communication fault
[B/D Type], [Fault
Description]
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Fault Description
0: SPI , 1: I2C , 2: IO
CAN , 3: Main CAN, 4:
UI CAN, 4: Ext CAN,
6: UART failure
Fault
2
internal memory fault
IO board /
Main board
Memory fault
[B/D Type], [Fault
Description]
Fault Description
0: Internal RAM, 1:
External RAM , 2:
Code memory, 3:
EEPROM, 4: Flash
Fault
3
Catalog memory corrupted
UI
Catalog memory fault
Fault
4
Internal HW fault
IO board /
Main board
Internal hardware
fault
[B/D Type]
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Fault
5
Sensor circuit fault
IO board
Sensor circuit fault
CH: xx, Code: xxx
Code
0: Gain setting error,
1: signal conditioning
circuit error
