Honeywell Touchpoint Plus Technical Handbook

Event Codes
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 148 Technical Handbook
Event
Type
Code
Long Description
Triggered
Display in Event
History
Details
Fault
6
Supplied voltage fault
IO board /
Main board
Supplied voltage fault
[B/D Type], Code: xxx
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Code
0: Vapp low, 1: V5
low, 2: V3.3 low, 3:
V12 low, 4: V9 low
Fault
7
Internal software failure
IO board /
Main board
Internal software
fault
[B/D Type], Code: xxx
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Code
0: BUFFER
OVERFLOW,
1: instruction test
failed
2: Sequence Checking
failed
Fault
8
Modbus communication failure
IO board
Modbus Comm Fault
CH: xx, Node: xx
Fault
9
Sensor fault (including signal range fault)
IO board
Sensor Fault
CH: xx, [B/D Type],
Code: xx
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Code
0 : bead open/short
1 : line open/short
2 : detector short
3 : operating voltage
fault
4: driver current fault
Fault
10
Analogue output mismatched
IO board
mA Output Error
CH: xx
Fault
11
Relay not controlled
IO board /
Main board
Relay Output Error
CH: xx
Fault
12
Remote fault informed by detector
(depending on fault signal range)
IO board
Detector In Fault
CH: xx, [B/D Type]
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
