6.1.2 The Configuration Menu
The Configuration Menu contains all of the basic system settings that are entered on installation / commissioning. It
should not need updating unless there are changes to the system or requirements. Access is restricted to Service or
Admin users.
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Configuration
Channel Settings
Channel Number Select
Remove
Enable
Disable
Select (3 windows)>Edit>Review>Apply>Update
Module Control Panel
Module Select
Refresh
Add
Remove
Replace
General
Date / Time
Change
Language
Change
Service Contact
Change
Home Settings
Default Home screen layout
Timeout
Menu Timeout (5 100 Sec)
Authentication Timeout (15 100 Min)
Log Interval and
Threshold
Log Threshold
Enter %FSD
Log Interval
Enter Seconds
Display
LCD Backlight Timeout
Enter Seconds
LCD Backlight
Brightness
Enter %
Touch Panel Calibration
Wizard
Outputs
Dedicated Alarm
Contacts
Dedicated Audible Alarm 1 (1/2/3)
Dedicated Audible Alarm 2 (1/2/3)
Buzzer Options
Buzzer Option (Enable / Disable)
Activation on Warning (Enable / Disable)
Security
Password
Change / Reset (per user)
Remote Access
Remote Reset/Acknowledge (Enable / Disable)
Remote Inhibit (Enable / Disable)
Remote Inhibit Setting (NO / NC)
Config Manager
Import
Per Channel (Update File required)
Export
Keyboard (Input File Name) / Wizard
Network
Ethernet
DHCP / SIP Address (Keyboard)
Modbus RTU
Address Settings (Keyboard) Baud, Parity, D-
Bits
Configuration Menu
