Touchpoint Plus User Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 83 Technical Handbook
7.4 Menu Items and Access Levels
The table below details the menu items and access levels for the User Interface. The password hierarchy is
Administrator, then Service, then Operator. Broadly speaking, the Administrator can do everything, the Service
Engineer can edit channel configuration and do maintenance and calibration, and the Operator can view,
acknowledge and reset events. (Viewing basic System Information and Status does not require a password.)
A user can log in by touching the log in icon, selecting an access level and then entering a valid password.
Note: Logged in users are automatically timed out after fifteen minutes of activity. For security reasons do not leave
the Touchscreen unattended while logged in.
Note: If user fails the password 10 times consecutively, Touchpoint Plus log-in is locked for all access levels. After
10 minutes, log-in becomes available.
Note: Admin account is only valid for authorized service engineer and its delegation. The user is responsible for
permitting the use of admin account under special maintenance case, e.g. maintenance << Service Mode << Electronic
Adjustment.
There are two kinds of timeout in menu mode. One is and the other is time .
With the display will change to a higher menu and then back to the Channel Status screen if there is
no touch input for a pre-set time. The default menu timeout is 90 seconds, but this can be changed using menu
options Configuration>General>Timeout.
For security reasons will log you out automatically when there is no Touchscreen activity
during the set time. Changes may be lost and the user will have to log in again.
Items with a clock symbol time out after 15 minutes of inactivity.
The default time out is 10 minutes for the pop-up menu.
Key: = Allowed, = Denied, = Fixed timeout
= sub-menu, = sub-sub-menu
