Honeywell Touchpoint Plus Technical Handbook

Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 140 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Target Gas Name
16 characters
mV Input
R/W
Alphanumeric
Character
Range
16 chars
Write available when:
Detector Name- User
Detector
Target Gas Unit
%, ppm, %LEL, %VOL, mA, User (6chars)
mV Input
R/W
Alphanumeric
Character
Range
%
Write available when:
Detector Name- User
Detector
mg/m3, g/m3, %VOL,
ppm, %LEL, UEG,
Ratio, %LEL x M, ppm x m,
EG x m, %Vol x m, LEL.m,
LEL%.m, %V/V, mA, kppm,
oC, oF, %RH
Target Gas Digit
Numbers of decimal point
mV Input
R/W
0~3
1
Changed by full scale setting
Target Resolution
Resolution
mV Input
R/W
0.1
0.1
0.01, 0.1, 0.2, 0.5, 1, 2, 5,
10, 20, 50, 100
Inhibit Time-out
Inhibit Time-out
mV Input
R/W
0~60
10
0: Disable, minute
Alarm Latch
Alarm will be continued until manual user
reset if latching is enabled.
mV Input
R/W
Disable/Enable
Enable
per channel
Calibration Interval
0, 30 to 365
mV Input
R/W
0, 30 to 365
180
0: Disable
Target Full Range
1, 100, 1000, 10000, User
mV Input
R/W
100
100
Write available when:
Detector Name- User
Detector
Threshold Alarm
Hysteresis
Alarm hysteresis is to avoid the alarm from
frequent on/off when the gas reading is
close to the alarm threshold.
mV Input
R/W
0~10
2% of Full range
Alarm 1 Enable
Alarm 1 enable/disable
mV Input
R/W
Disable/Enable
Disable
Alarm 1 Threshold
Trigger
Alarm 1 trigger option (Rising or Falling)
mV Input
R/W
Rising/Falling
Rising
Alarm 1 Level
Alarm 1 threshold concentration
mV Input
R/W
2~100%FS
20% of Full range

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
