Honeywell Touchpoint Plus Technical Handbook

Event Codes
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 153 Technical Handbook
Event
Type
Code
Long Description
Triggered
Display in Event
History
Details
Info
45
mA Output calibration successful
UI Board
mA output
calibration passed
CH: xx
Info
46
mA Output calibration failed
UI Board
mA output
calibration failed
CH: xx
Info
47
mV baseline adjusted successfully
UI Board
mV base adjusted
CH: xx
Info
48
Failed in mV baseline adjustment
UI Board
mV base not adjusted
CH: xx
Info
49
mV bridge current adjusted successful
UI Board
mV current adjusted
CH: xx
Info
50
Failed in mV bridge current adjustment
UI Board
mV current not
adjusted
CH: xx
Info
51
Performed LCD screen test
UI Board
RESERVED
Info
52
Performed LED test
UI Board
RESERVED
Info
53
Performed buzzer test
UI Board
RESERVED
Info
54
Relay output forced
UI Board
Forced relay
CH: xx
Info
55
Relay output released
UI Board
Released Relay
CH: xx
Info
56
Analogue output forced
UI Board
Forced mA output
CH: xx, xxx mA
Info
57
Analogue output released
UI Board
Release mA output
CH: xx
Info
58
Started input channel test
UI Board
RESERVED
Info
59
Ended input channel test
UI Board
RESERVED
Info
60
Started Relay Output Simulation
UI Board
Started Relay Sim.
CH: xx
Info
61
Ended Relay Output Simulation
UI Board
Ended Relay Sim.
CH: xx
Info
62
Updated Firmware
UI Board
FW Updated
[B/D Type], Ver: x.x.x
Type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Info
63
Firmware Update failed
UI Board
FW Update Failed
[B/D Type], Ver: x.x.x
B/D type
0:Main, 1:UI, 2:mA
Input, 3 : mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Info
64
Updated sensor catalogue
UI board
Catalog Updated
Ver: xxxx
