Commissioning
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 68 Technical Handbook
11) Touch and enter the [Calibration Interval] and the [Span Gas Concentration] that was used for First Span, then
select [Next]:
12) Touch and change the following [Channel Settings]:
Note values are relevant and actionable. These values shall only be
changed by Honeywell Authorised personnel or by qualified personnel trained in accordance with this manual.
Note: [Inhibit Timeout] is a failsafe timeout in case the User forgets to reset a local inhibit. It does not affect Remote
Inhibit switches that are either on or off (e.g. key switches).
13) Touch Finish>Apply>Update.
14) Repeat to configure other input channels.
Note: You will have to redo any unsaved changes if the system reverts to an earlier window due to inactivity.
