HP Compaq nc6000 - Notebook PC Hardware Guide

4–12 Hardware Guide
Drives
Removing a Drive from the MultiBay
Ä
CAUTION: To prevent system lockup and loss of information, stop the
drive before removing it. To stop the drive:
■ Windows 2000—Select the Unplug or Eject Hardware icon on
the taskbar, then select the drive you want to remove. When it is
safe to remove the drive, a message is displayed.
■ Windows XP—Select the Safely Remove Hardware icon on the
taskbar, then select the drive you want to remove. When it is safe to
remove the drive, a message is displayed. (To display taskbar
icons, select Show Hidden Icons in the system tray.)
Ä
CAUTION: To protect the MultiBay when no device is inside, insert the
weight saver in the bay. This device prevents damage to the MultiBay
and does not increase notebook weight.
1. If the drive has a media tray, remove the media, then close
the tray.
2. Stop the drive as instructed in the preceding caution.
3. Turn the notebook upside down.
4. Slide the MultiBay release latch 1 toward the rear of
the notebook.
5. Pull the drive or drive assembly 2 out of the MultiBay.
333644-001.book Page 12 Thursday, July 10, 2003 2:56 PM

HP Compaq nc6000 - Notebook PC Specifications

General

Processor	Intel Pentium M
Chipset	Intel 855PM
Storage	30 GB to 60 GB HDD
Hard Drive Interface	ATA-100
Battery	6-cell Lithium-Ion
Operating System	Windows XP Professional
RAM	256 MB, upgradable to 2 GB
Graphics	ATI Mobility Radeon 9600
Display	14.1-inch
Display Resolution	1024 x 768 or 1400 x 1050
Optical Drive	DVD-ROM, CD-RW/DVD Combo, or DVD±RW
Networking	10/100/1000 Ethernet
Ports	2 x USB 2.0, VGA, parallel, serial, headphone, microphone
