Drives
Hardware Guide 4–13
MultiBay Drive Media
This section provides information on using optical discs (such as
CD-ROMs and DVDs) and diskettes in the MultiBay.
Inserting an Optical Disc
1. Turn on the notebook.
2. Press the release button 1 on the drive bezel to release the
media tray.
3. Pull the tray out 2 until it is fully extended. Position a CD or
one-sided DVD over the tray with the label side up.
4. Gently press the disc 3 onto the tray spindle until the disc
snaps into place. Handle the disc by the edges, not the flat
surfaces. If the media tray is not fully extended, tilt the disc to
position it over the tray spindle, then press it into position.
5. Close the media tray.
✎
After you insert a DVD, a short pause is normal as Autorun opens
the DVD and WinDVD player.
333644-001.book Page 13 Thursday, July 10, 2003 2:56 PM
