HP Compaq nc6000 - Notebook PC - Rear View Components

Notebook Features
Hardware Guide 1–13
Rear View Components
Rear view component descriptions
Item Component Description
1
Power connector Connects an AC adapter or an optional
Automobile Power Adapter/Charger, or
Aircraft Power Adapter.
2
Serial connector Connects an optional serial device.
3
Parallel connector Connects an optional parallel device,
such as an external diskette drive bay
or a printer.
4
RJ-45 network jack Connects a network cable.
5
USB connector Connects USB 1.1- and 2.0-compliant
devices to the notebook using a
standard USB cable.
6
Self-powered USB
connector
Connects USB 1.1- and 2.0-compliant
devices to the notebook using a
standard USB cable, or connects
an optional External MultiBay to
the notebook using the External
MultiBay-powered USB cable.
7
External monitor connector Connects an optional external monitor
or overhead projector.
