Audio and Video
Hardware Guide 5–5
Using the S-Video Jack
To connect a video device to the S-Video jack:
1. Plug either end of the S-Video cable 1 into the S-Video jack
on the notebook.
2. Connect the other end of the cable 2 to the video device as
instructed in the documentation included with the device.
✎
If the S-Video jack on the notebook is not accessible because the
notebook is docked into an Advanced Port Replicator, you can
connect the device to the S-Video jack on the optional Advanced
Port Replicator.
333644-001.book Page 5 Thursday, July 10, 2003 2:56 PM
