6–6 Hardware Guide
Communication Devices
Setting Up an Infrared Transmission
For information about using infrared software, refer to your
operating system Help file.
To set up infrared devices for optimal transmission:
■ Prepare the infrared ports on both devices for transmission.
■ Position the devices so that their infrared ports face one
another at a distance no greater than 1 meter (3.3 feet).
■ Position the ports so that they face one another directly.
Because the maximum capture angle is 30 degrees, the ports
must be aligned no more than 15 degrees off-center.
■ Shield the ports from direct sunlight, flashing incandescent
light, and energy-saving fluorescent light.
■ Be sure that no signals from remote control or other wireless
devices, such as headphones or audio devices, aim at a port.
■ During the transmission, do not move either device and do
not allow objects or movement to disrupt the beam.
Using Standby with Infrared
Standby is not compatible with infrared transmission. If the
notebook is in Standby, an infrared transmission cannot be
initiated. If Standby is initiated during an infrared transmission,
the transmission stops. To resume from Standby, press the power
button. The transmission resumes when the notebook resumes
from Standby. However, any program that was using the infrared
transmission when Standby was initiated may not continue at the
point it was stopped. For example, if a program was printing
when Standby was initiated, the program resumes transmission
after the notebook resumes, but the print job may not resume.
333644-001.book Page 6 Thursday, July 10, 2003 2:56 PM
