HP 1606 - Nonport Side LED Activity for the 8;80 SAN Switch; Nonport Side LED Patterns During Normal Operation

Recommended actionStatus of hardwareLED colorLED name
No action required.Port is receiving light or signal
carrier at 4 Gb/s, but is not yet
online.
Steady amber (for
more than 5
seconds)
Nonport side LED activity for the 8/80 SAN Switch
Table 9 describes LEDs and recommended actions.
Table 9 Nonport side LED patterns during normal operation
Recommended actionStatus of hardwareLED colorLED name
Verify that the power supply is on
and seated and the power cord is
connected to a functioning power
source.
Power supply is not receiving
power or is off.
No lightPower supply
status
No action required.Power supply is operating nor-
mally.
Steady green
Do the following:
• Check the power cable connec-
tion.
• Verify the power supply is on.
• Replace the power supply FRU.
Power supply fault for one of the
following reasons:
• Power supply is switched off.
• Power cable is disconnected.
• Power supply has failed.
NOTE:
When the switch is first
powered on the power supply
status LED will show amber
until POST has completed.
Steady amber (for
more than five
seconds)
Do the following:
• Verify the fan FRU is seated.
• Verify the switch is on.
Fan assembly is not receiving
power.
No lightFan status
No action required.Fan assembly is operating nor-
mally.
Steady green
Do the following:
• Verify the fan FRU is enabled
(use the fanenable com-
mand).
• Replace the fan FRU.
Fan fault for one of the following
reasons:
• One or more of the fans in
the fan assembly has failed.
• The fan FRU was disabled by
the user.
NOTE:
When the switch is first
powered on, the fan status
LED will show amber until
POST has completed.
Steady amber (for
more than five
seconds)
8-Gb SAN Switch Hardware Reference Guide 63
