HP 1606 - Port Side LED Activity for the 1606 Extension SAN Switch; Fcoe Converged Network Switch Nonport Side LED Patterns

Table 12 describes the LEDs on the nonport side of the switch.
Table 12 FCoE Converged Network Switch nonport side LED patterns
Recommended actionStatus of hardwareLED colorLED name
Verify the power supply is on and
seated and the power cord is con-
nected to a functioning power
source.
Power supply is not receiving
power or is off.
No lightPower supply
status
No action required.Power supply is operating nor-
mally.
Steady green
Do the following:
• Check the power cable connec-
tion.
• Verify that the power supply is
powered on.
• Replace the power supply FRU.
Power supply is faulty.
NOTE:
When the switch is first
powered on, the power
supply status LED displays
steady amber until POST
completes.
Steady amber (for
more than 5
seconds)
Do the following:
• Verify the fan FRU is seated
correctly.
• Verify the switch is powered
on.
Fan assembly is not receiving
power.
No lightFan status
No action required.Fan assembly is operating nor-
mally.
Steady green
Do the following:
• Verify the fan FRU is enabled
(use the fanenable com-
mand).
• Replace the fan FRU.
Fan fault for one of the follow-
ing reasons:
• One or more of the fans in
the fan assembly has failed.
• The fan FRU has been dis-
abled.
NOTE:
When the switch is first
powered on, the fan status
LED displays steady amber
until POST completes.
Steady amber (for
more than 5
seconds)
Port side LED activity for the 1606 Extension SAN Switch
System activity and status can be determined through the activity of the LEDs on the 1606 Extension
SAN Switch. Figure 33 shows the LEDs on the port side of the 1606 Extension SAN Switch.
The LED states are as follows:
• No light
• Steady light
• Flashing light
The LEDs are either green or amber.
8-Gb SAN Switch Hardware Reference Guide 69
