HP 3500 Series Advanced Traffic Management Guide

3-36
Multiple Instance Spanning-Tree Operation
Configuring MSTP
The show spanning-tree <port-list> detail command indicates which ports have
PVST protection and/or PVST Filtering enabled.
Figure 3-14. Example of Show Spanning-tree Command Displaying PVST
Protection Enabled (Yes)
HP Switch(config)# show spanning-tree 7 detail
.
.
.
Port : 7
Status : Down
BPDU Protection : Yes
BPDU Filtering : No
PVST Protection : Yes
PVST Filtering : No
Errant BPDU Count : 0
Root Guard : No
TCN Guard : No
.
.
.
