3-81

Multiple Instance Spanning-Tree Operation

STP Loop Guard

Figure 3-41. Example of Spanning-tree Configuration Information

Detailed Spanning Tree information is shown in Figure 3-42.

HP Switch(config)# show spanning-tree config

Multiple Spanning Tree (MST) Configuration Information

STP Enabled [No] : Yes

Force Version [MSTP-operation] : MSTP-operation

Default Path Costs [802.1t] : 802.1t

MST Configuration Name : 0024a8d13a40

MST Configuration Revision : 0 Switch Priority : 32768

Forward Delay [15] : 15 Hello Time [2] : 2

Max Age [20] : 20 Max Hops [20] : 20

| Path Prio Admin Auto Admin Hello Root Loop TCN BPDU

Port Type | Cost rity Edge Edge PtP Time Guard Guard Guard Flt

---- --------- + --------- ---- ----- ---- ----- ------ ----- ----- ----- ---

1 100/1000T | Auto 128 No Yes True Global No No No No

2 100/1000T | Auto 128 No Yes True Global No Yes No No

3 100/1000T | Auto 128 No Yes True Global No No No No

4 100/1000T | Auto 128 No Yes True Global No No No No

5 100/1000T | Auto 128 No Yes True Global No No No No

6 100/1000T | Auto 128 No Yes True Global No No No No
