HP 3500 Series Advanced Traffic Management Guide

5-31
Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
The show qos resources command displays the number of hardware resources
currently in use by QoS policies as well as other software features.
Figure 5-8. Displaying the Hardware Resources Used by Currently Configured QoS Policies
Note ACLs and QoS policies share the same application port ranges. If a new QoS
policy specifies a port range that is already configured for one or more ACLs,
the QoS column increases by 1, but the “Application Port Ranges Available”
HP Switch# show qos resources
Resource usage in Policy Enforcement Engine
| Rules | Rules Used
Ports | Available | ACL | QoS | IDM | VT | Mirror | Other |
------+-------------+-------+-------+-------+-------+--------+-------|
1-24 | 3014 | 15 | 11 | 0 | 1 | 0 | 3 |
25-48 | 3005 | 15 | 10 | 10 | 1 | 0 | 3 |
A | 3017 | 15 | 8 | 0 | 1 | 0 | 3 |
| Meters | Meters Used
Ports | Available | ACL | QoS | IDM | VT | Mirror | Other |
------+-------------+-------+-------+-------+-------+--------+-------|
1-24 | 250 | | 5 | 0 | | | 0 |
25-48 | 251 | | 4 | 0 | | | 0 |
A | 253 | | 2 | 0 | | | 0 |
| Application |
| Port Ranges | Application Port Ranges Used
Ports | Available | ACL | QoS | IDM | VT | Mirror | Other |
------+-------------+-------+-------+-------+-------+--------+-------|
1-24 | 3014 | 2 | 0 | 0 | | 0 | 0 |
25-48 | 3005 | 2 | 0 | 0 | | 0 | 0 |
A | 3017 | 2 | 0 | 0 | | 0 | 0 |
0 of 8 Policy Engine management resources used.
Key:
ACL = Access Control Lists
QoS = Device & Application Port Priority, QoS Policies, ICMP rate limits
IDM = Identity Driven Management
VT = Virus Throttling blocks
Mirror = Mirror Policies, Remote Intelligent Mirror endpoints
Other = Management VLAN, DHCP Snooping, ARP Protection, Jumbo IP-MTU.
Resource usage includes resources actually in use, or reserved for future
use by the listed feature. Internal dedicated-purpose resources, such as
port bandwidth limits or VLAN QoS priority, are not included.
Incldues the hardware resources used
by currently applied QoS policies.

HP 3500 Series Specifications

General

Model	HP 3500 Series
Layer	Layer 3
MAC Address Table Size	16, 000 entries
Type	Managed
Uplink	SFP
PoE	Optional
Management	Web, CLI, SNMP
Routing Protocol	Static, RIP
Power Supply	Internal
Form Factor	1U rack-mountable
Jumbo Frame Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Ports	24 or 48 10/100/1000 ports
