HP 3500 Series Advanced Traffic Management Guide

8-30
Classifier-Based Software Configuration
Traffic Classes
The following example shows TCP and UDP traffic routed on different net-
work paths. First the traffic classes are created, then the PBR policy is created,
and lastly the PBR policy is applied to an interface.
Figure 8-9. Example of Creating Classes and Polices for PBR
HP Switch(config)# class ipv4 TCP
HP Switch(config-class)# match tcp 10.0.8.1/24 15.29.16.104/24 eq 80
HP Switch(config-class)# match tcp 10.0.8.1/24 15.29.16.104/24 eq 22
HP Switch(config-class)# match tcp 10.0.8.1/24 15.29.16.104/24 eq 23
HP Switch(config-class)# exit
HP Switch(config)# class ipv4 UDP
HP Switch(config-class)# match udp 10.0.8.1/24 15.29.16.104/24 eq 80
HP Switch(config-class)# match udp 10.0.8.1/24 15.29.16.104/24 eq 22
HP Switch(config-class)# match upd 10.0.8.1/24 15.29.16.104/24 eq 23
HP Switch(config-class)# exit
HP Switch(config)# class ipv6 TCP
HP Switch(config-class)# match tcp 2001::1/64 3001::1/64 eq 80
HP Switch(config-class)# match tcp 2001::1/64 3001::1/64 eq 22
HP Switch(config-class)# match tcp 2001::1/64 3001::1/64 eq 23
HP Switch(config-class)# exit
HP Switch(config)# class ipv6 UDP
HP Switch(config-class)# match udp 2001::1/64 3001::1/64 eq 80
HP Switch(config-class)# match udp 2001::1/64 3001::1/64 eq 22
HP Switch(config-class)# match udp 2001::1/64 3001::1/64 eq 23
HP Switch(config-class)# exit
HP Switch(config)# policy pbr TCP_UDP
HP Switch(policy-pbr)# class ipv4 TCP
HP Switch(policy-pbr-class)# action ip next-hop 20.0.0.1
HP Switch(policy-pbr-class)# action interface null
HP Switch(policy-pbr-class)# exit
HP Switch(policy-pbr)# class ipv4 UDP
HP Switch(policy-pbr-class)# action ip default-next-hop 30.0.0.1
HP Switch(policy-pbr-class)# action interface tunnel 3
HP Switch(policy-pbr-class)# exit
HP Switch(policy-pbr)# class ipv6 TCP
HP Switch(policy-pbr-class)# action ip next-hop 20.0.0.1
HP Switch(policy-pbr-class)# exit
HP Switch(policy-pbr)# class ipv6 UDP
HP Switch(policy-pbr-class)# action ip next-hop 30.0.0.1
HP Switch(policy-pbr-class)# exit
HP Switch(policy-pbr)# exit
HP Switch(config)# vlan 10
HP Switch(vlan-10)# service-policy TCP_UDP in

HP 3500 Series Specifications

General

Model	HP 3500 Series
Layer	Layer 3
MAC Address Table Size	16, 000 entries
Type	Managed
Uplink	SFP
PoE	Optional
Management	Web, CLI, SNMP
Routing Protocol	Static, RIP
Power Supply	Internal
Form Factor	1U rack-mountable
Jumbo Frame Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Ports	24 or 48 10/100/1000 ports
