HP 8591C

I
-
Channel Measurements
Making Channel Measurements
System frequency
response test
1. To perform a cable TV overall system frequency response, press the
following analyzer keys:
Main i of 3 Main 2 of 3
SYSTEM FRQ RESP
2. Press ENTER STRT FRQ , enter the start frequency of your system, then
press Cm].
3. Press ENTER STOP FRQ , enter the stop frequency of your system, then
press [ENTER).
NOTE
The start and stop frequencies for the measurement should be the same as the reference trace for
meaningful results.
4. If you want to use a reference trace that was previously stored in the
analyzer’s internal memory and you know the trace register number of
the reference trace, press RECALL FRM INT . See Chapter 5 for more
information about using RECALL FRM INT
5. If you want to create a reference trace, press CONTINUE ,
TAKE REF TRACE See Chapter 5 for more information about using
TAKE REF TRACE.
6. After the reference trace appears on screen, select FAST SWEEP or
SLOW SWEEP , then, if you want to save the reference trace, press
SAVE TRB TO INT , enter a register number, then press C-1.
7. Press DO FRQ RESP TST to perform the measurement. See
Figure 2-39. Also, see Chapter 5 for more information about using
DO FRQ RESP TST
2-57
