USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access. The System configuration
panel is displayed.
2. Click on the plus sign next to Configure in the tree view to display the configuration options.
3. Select the Trunk
link to display a table listing the configured trunk groups.
This display shows the following information.
Duplex The mode of the port, which can be one of the following:
• None – The link on the primary trunk port is down.
• Full – The primary port is running in full-duplex.
• Half – The primary port is running in half-duplex.
Note: This field and the following fields apply only to operational trunk
groups.
Speed The speed set for the port. The value can be one of the following:
• None – The link on the primary trunk port is down.
• 10 – The port speed is 10 Mbps.
• 100 – The port speed is 100 Mbps.
• IG – The port speed is 1000 Mbps.
Tag Indicates whether the ports have 802.1q VLAN tagging. The value
can be Yes or No.
Priority Indicates the Quality of Service (QoS) priority of the ports. The
priority can be a value from 0 – 7.
Active Ports The number of ports in the trunk group that are currently active.
Ports The ports in the trunk group.
Link_Status The link status or each port in the trunk group.
Load Sharing The number of traffic flows currently being load balanced on the trunk
ports. All traffic exchanged within the flow is forwarded on the same
trunk port. For information about trunk load sharing, see the “Trunk
Group Load Sharing“ section in the “Configuring Trunk Groups and
Dynamic Link Aggregation“ chapter of the
Installation and Getting
Started Guide
.
Table 5.4: Web Management Trunk Group Information
This Field... Displays...
Connection Type The type of trunk group, which can be one of the following:
• Server – The trunk group is connected to a server.
• Switch – The trunk group is connected to another Routing Switch.
Table 5.3: CLI Trunk Group Information (Continued)
This Field... Displays...
