Table 15 Required configurations on ports of different link types in order for the ports to support tagged
voice traffic
Port link type
Voice VLAN
assignment
mode
Support for
tagged voice
traffic
Configuration requirements
Automatic
Access
Manual
No —
Automatic
Configure the PVID of the port, which cannot be
the voice VLAN, and assign the port to its PVID.
Trunk
Manual
Yes
Make all the configurations required for the
automatic mode, and assign the port to the voice
VLAN.
Automatic
Configure the PVID of the port, which cannot be
the voice VLAN, and configure the port to permit
packets of its PVID to pass through untagged.
Hybrid
Manual
Yes
Make all the configurations required for the
automatic mode, and configure the port to permit
packets of the voice VLAN to pass through
tagged.
• IP phones send untagged voice traffic
When IP phones send untagged voice traffic, you can only configure the voice traffic receiving ports on
the device to operate in manual voice VLAN assignment mode.
Table 16 Required configurations on ports of different link types in order for the ports to support tagged
voice traffic
Port link type
Voice VLAN
assignment
mode
Support for
untagged voice
traffic
Configuration requirements
Automatic No —
Access
Manual Yes Configure the PVID of the port as the voice VLAN.
Automatic No —
Trunk
Manual Yes
Configure the PVID of the port as the voice VLAN
and assign the port to the voice VLAN.
Automatic No —
Hybrid
Manual Yes
Configure the PVID of the port as the voice VLAN
and configure the port to permit packets of the
voice VLAN to pass through untagged.
NOTE:
• The PVID of a port is VLAN 1 by default. You can change the PVID and assign a port to certain VLANs
by using commands. For more information, see the chapter “VLAN configuration.”
• Use the display interface command to display the PVID of a port and the VLANs to which the port
is
assigned.
116
