HP A3100-8 v2 SI - CDP-Compatible LLDP Configuration Example (Available Only on the A3100 V2

LLDP neighbor information last changed time: 0 days,0 hours,5 minutes,20 seconds
Transmit interval : 30s
Hold multiplier : 4
Reinit delay : 2s
Transmit delay : 2s
Trap interval : 5s
Fast start times : 3
Port 1 [Ethernet1/0/1]:
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
Polling interval : 0s
Number of neighbors : 1
Number of MED neighbors : 1
Number of CDP neighbors : 0
Number of sent optional TLV : 0
Number of received unknown TLV : 5
Port 2 [Ethernet1/0/2]:
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
Polling interval : 0s
Number of neighbors : 0
Number of MED neighbors : 0
Number of CDP neighbors : 0
Number of sent optional TLV : 0
Number of received unknown TLV : 0
As the sample output shows, Ethernet 1/0/2 of Switch A does not connect to any neighboring devices.
CDP-compatible LLDP configuration example (available only on
the A3100 v2 EI)
NOTE:
The A3100 v2 SI Switch Series does not support voice VLAN and CDP-compatible LLDP configurations.
Network requirements
As shown in Figure 61:
• Ethernet 1/0/1 and Ethernet 1/0/2 of Switch A are each connected to a Cisco IP phone.
• Configure voice VLAN 2 on Switch A. Enable CDP compatibility of LLDP on Switch A to allow the
Cisco IP phones to automatically configure the voice VLAN, confining their voice traffic within the
voice VLAN and isolating the voice traffic from other types of traffic.
179
