Hardware options installation 39
13.
Connect all the drive cables.
14. Install the system air baffle (on page 22).
15. If removed, install the PCI air baffle ("Install the PCI air baffle" on page 20).
16. Install the front bezel (on page 19).
17. Install the access panel (on page 18).
18. Return the server to an upright position.
19. Connect each power cord to the server.
20. Connect each power cord to the power source.
21. Power up the server.
Installing a hot-plug drive
CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
To install the component:
1. Remove the drive blank.
