Hardware options installation 63
DIMM type DIMM rank Capacity (GB)
Maximum capacity
for one processor
(GB)
RDIMM
Single-rank
8
64
RDIMM
Dual-rank
8
64
RDIMM
Dual-rank
16
128
LRDIMM
Dual-rank
16
128
RDIMM
Dual-rank
32
256
Maximum memory capacity - Intel Xeon E5-2600 v4 processor installed
DIMM type DIMM rank Capacity (GB)
Maximum capacity
for one processor
(GB)
RDIMM
Single-rank
8
64
RDIMM
Single-rank
16
128
RDIMM
Dual-rank
16
128
RDIMM
Dual-rank
32
256
SmartMemory
SmartMemory authenticates and unlocks certain features available only on Qualified memory and verifies
whether installed memory has passed Hewlett Packard Enterprise qualification and test processes.
Qualified memory is performance-tuned for ProLiant and BladeSystem servers and provides future
enhanced support through Active Health and manageability software.
Memory subsystem architecture
The memory subsystem in this server is divided into channels. The processor supports four channels, and
each channel supports two DIMM slots, as shown in the following table:
Channel
Population order
Slot number
1
A
E
8
7
2
B
F
6
5
3
C
G
1
2
4
D
H
3
4
For the location of the slot numbers, see "DIMM slot locations (on page 11)."
This multi-channel architecture provides enhanced performance in Advanced ECC mode. This
architecture also enables Online Spare Memory mode.
DIMM slots in this server are identified by number and by letter. Letters identify the population order. Slot
numbers indicate the DIMM slot ID for spare replacement.
