NOTE: Part numbers are found by using the part nomenclature from this list to select the correct
part from the HP Partsurfer. If a part that is not listed in the FRU list needs to be replaced, the Base
Unit Repair Kit is required. Remove processors, DIMMs, HDDs, DVD and adapter boards and
transfer these to the new base unit in the base unit. Ensure all jumper and switch settings on the
old board are transferred to the new board.
This parts list is current as of the publication date of this document. To find the most current parts
list for your server, go to http://partsurfer.hp.com/search.aspx.
Table 1 Field Replaceable Parts (FRU) List
Part Number
Exchange
Part Number
ReplacementDescriptionItem No.
PCA BOARDS
AB430-67009AB430-67004PCI Backplane Assembly1
AB587-60002(Optional) Management Processor Card (A7231-66580)9
AB587-60006A7231-66550Display Panel5
MEMORY
A6967AX256 MB DIMM20
A6968AX512 MB DIMM20
A6969-69001A6969AX1 GB DIMM20
A6835-69001A6970AX2 GB DIMM20
INTERNAL DISKS/REMOVABLE MEDIA
A7835-6900336GB, 10K RPM SCSI Disk (A9922A)6
A9897-6900173GB 10K RPM SCSI Disk (A9897A)6
A9898-69002146GB 10K RPM SCSI Disk (A9898A)6
AB423-69001300GB 10K RPM SCSI Disk6
AB299-67001DVD ROM (AB299A)7
AB350-67001DVD+RW (AB350A)7
FANS
AB430-67007System Fans (two locations)17
AB430-67006Power Supply Fans3
PROCESSORS
AB481-69001AB481AX1.3 GHz CPU (AB481AX)14
AB482-69001AB482AX1.5 GHz CPU (AB482AX)14
CPU Power Pod (0950-4550)15
5069-5441IPF CPU Install Tool Kit
MISCELLANEOUS
0957-2123Power Supply2
System Battery (3.3vdc, BR-type, 250mAh)16
Management Processor Battery (3.3vdc, BR-type, 250mAh)8
AB430-67013Top Cover12
Field Replaceable Parts (FRU) List 71
