3 Removing and Replacing Components
This chapter provides instructions for removing and replacing components of the HP Integrity rx1620
Server.
Safety Information
Follow the procedures listed below to ensure safe handling of components and to prevent harm to
both you and the HP Server:
• Use an antistatic wrist strap and a grounding mat, such as those included in the Electrically
Conductive Field Service Grounding Kit (P/N 9300-1155).
• Handle accessory boards and components by the edges only. Do not touch any metal-edge
connectors or any electrical components on accessory boards.
• Do not wear clothing subject to static charge build-up, such as wool or synthetic materials.
WARNING! Hazardous voltages are present inside the HP Server. Always remove AC power
from the server and associated assemblies while working inside the unit. Serious injury may result
if this warning is not observed.
Service Tools Required
Service of this product may require one or more of the following tools:
• IPF CPU Install Tool Kit (P/N 5069-5441), consisting of:
Disposable ESD Kit◦
◦ Label-less CPU install tool (2.5mm hex and Torx 15)
• 1/4 inch Flat Blade Screwdriver
• Phillips No. 1 Screwdriver
• ACX-10 Torx Screwdriver
• ACX-15 Torx Screwdriver
• ACX-25 Torx Screwdriver
Accessing a Rack Mounted Server
The HP Integrity rx1620 Server is designed to be rack mounted. The following procedure explains
how to gain access to an HP Integrity rx1620 Server that is mounted in an approved rack.
WARNING! Ensure that all anti-tip features (front and rear anti-tip feet installed with adequate
ballast properly placed) are employed prior to extending the server.
Extend the Server from the Rack
NOTE: Ensure that there is enough area (Approximately 1.5 meters [4.5 ft.] to fully extend the
server out the front and work on it.
To extend the server from the rack, perform the following steps:
1. Remove the T-25 screws that fasten the server to the rack.
2. Slowly pull the unit forward. The server is fully extended when the rail clips are locked in
place. When fully extended, the top cover is fully accessible.
28 Removing and Replacing Components
