8-36 Parts and Diagrams
EN
Table 8-21. Internal Components of 500-sheet Feeder
Item No. Part No. Quantity Description
1 RB1-8890-000CN 1 Guide, Paper
2 RB1-8873-000CN 1 Support, Paper Guide
3 RB1-8876-000CN 1 Cover, Feeder, Right
4 RG5-3711-000CN 1 Cable, Sensor
5 RG5-2673-000CN 1 Feeder Controller PCA
6 RB1-8887-000CN 1 Levers, Tray Sensing
7 RB1-8886-000CN 1 Cover, Feeder PCA
8 RG5-3712-000CN 1 Connector, Lower Tray (with cable)
9 RB1-8107-000CN 4 Foot
10 RG5-2669-000CN 1 Cover, Feeder, Left
11 RS5-2652-000CN 1 Spring, Tray Lock
12 RG5-2672-000CN 1 Paper Pickup Drive Assembly
(500-sheet)
13 XA9-0917-000CN 1 Screw, M3x16, Feed Modules
14 VS1-6176-000CN 1 Connector (250- and 500-sheet Feeder)
