8-40 Parts and Diagrams
EN
Table 8-23. 500-sheet Tray
Item No. Part No. Quantity Description
1 RB1-8947-000CN 1 Panel, Roller Access
2 RF5-2489-000CN 1 Mounting Assembly Separation Roller
3 RB1-8948-000CN 1 Gear, Separation Roller Drive
4 RB1-8946-000CN 1 Bushing, Separation Roller
5 RB1-8945-000CN 1 Coupler, Separation Roller
6 RS5-2622-000CN 1 Spring, Separation Roller Tension
7 RB1-8949-000CN 1 Paper Stop, 500-sheet Tray
8 RF5-2490-000CN 1 Roller
9 RB1-8974-000CN 1 Clutch, Separation Roller
