8-44 Parts and Diagrams
EN
Table 8-25. Internal Components of 250-sheet Feeder (2 of 2)
Item No. Part No. Quantity Description
1 RG5-2679-000CN 1 Cover Assembly, Feeder, Right Lower
2 RG5-2680-000CN 1 Cover Assembly, Feeder, Left Lower
3 RB1-8907-000CN 1 Cover, Feeder PCA
4 RG5-2685-000CN 1 Feeder, Control PCA
5A RB1-9033-000CN 1 Levers, Tray Sensing Upper
5B RB1-9034-000CN 1 Levers, Tray Sensing Lower
6 XA9-0917-000CN 1 Screw, M3x16, Feed Modules
7 RG5-2684-000CN 1 Paper Pickup Drive Assembly, Lower
(250-sheet)
8 VS1-6176-000CN 1 Connector (250- and 500-sheet Feeder)
