8-50 Parts and Diagrams
EN
2 RG5-2690-000CN 1 Paper Pickup Drive Assembly, Optional
(500-sheet)
3 RB1-8865-000CN 4 Roller
4 VS1-6174-000CN 1 Connector
5 RB1-8928-000CN 1 Tray Identifier Plunger
6 RS5-2967-000CN 1 Spring, Compression
7 RB1-8915-000CN 1 Frame, Right
8 RG5-2688-000CN 1 Left Frame Assembly
9 RB1-8927-000CN 1 Spring, Leaf
10 RG5-3822-000CN 1 Paper Feeder Cable
11 RB1-8924-000CN 2 Guide, Lower Tray
12 RG5-3821-000CN 1 Lower Tray Logic PCA
13 RS5-1179-000CN 2 Bearing, Transport Roller
Table 8-29. Internal Components of Optional 500-sheet Feeder (continued)
Item No. Part No. Quantity Description
