Port Status and Basic Configuration
Viewing Port Status and Configuring Port Parameters
Per-Port MDI
Configuration
Figure 10-8. Example of Displaying the Current MDI Configuration
Per-Port MDI
Operating Mode
Figure 10-9. Example of Displaying the Current MDI Operating Mode
Note Port Response to Switch Software Updates
■ Switch software updated from xx.xx.xx or earlier
1. Copper ports in auto-negotiation still default to auto-mdix mode.
2. Copper ports in forced speed/duplex default to mdix mode.
The default is auto-mdix. If the switch is reset to the factory defaults, these
ports are configured as auto-mdix. Use the following CLI command to change
the setting for individual ports:
interface < port-list > mdix-mode < automdix | mdi | mdix >
10-14
