Monitoring and Analyzing Switch Operation

Port and Static Trunk Monitoring Features

Move the cursor to the Monitoring Port parameter.

Port where monitored traffic exits the switch.

Figure B-20. How To Select a Monitoring Port

5. Use the Space bar to select the port to use for monitoring.

6. Use the down arrow key to move the cursor to the Action column for the

individual ports and position the cursor at a port you want to monitor.

7. Press the Space bar to select Monitor for each port and trunk that you want

monitored. (Use the down arrow key to move from one interface to the

next in the Action column.)

8. When you finish selecting ports to monitor, press

[Enter], then press [S] (for

ave) to save your changes and exit from the screen.

9. Return to the Main Menu.

B-25
