RADIUS Authentication and Accounting
Configuring the Switch for RADIUS Authentication
For example, suppose you have configured the switch as shown in figure 3-3
and you now need to make the following changes:
1. Change the encryption key for the server at 10.33.18.127 to "source0127".
2. Add a RADIUS server with an IP address of 10.33.18.119 and a server-
specific encryption key of "source0119".
Figure 3-3. Sample Configuration for RADIUS Server Before Changing the Key and
Adding Another Server
To make the changes listed prior to figure 3-3, you would do the following:
Figure 3-4. Sample Configuration for RADIUS Server After Changing the Key and Adding Another Server
To change the order in which the switch accesses RADIUS servers, refer to
“Changing RADIUS-Server Access Order” on page 3-27.
Changes the key
for the existing
server to
"source0127" (step
Adds the new
RADIUS server
with its required
"source0119" key.
Lists the switch’s
new RADIUS
server
configuration.
Compare this with
!FishSecurity.book Page 11 Thursday, October 10, 2002 9:19 PM

HP ProCurve Switch 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	Layer 2
Form Factor	Rack-mountable
Flash Memory	8 MB
Jumbo Frame Support	Yes
Power Supply	Internal
Management	Web, CLI, SNMP
Features	VLAN support, IGMP snooping, QoS
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	15% to 95% (non-condensing)
Ports	48 x 10/100
MAC Address Table Size	8, 000 entries
