5-4
Configuring Port-Based Access Control (802.1x)
How 802.1x Operates
How 802.1x Operates
Authenticator Operation
This operation provides security on a direct link between a single client and
the switch, where both devices are 802.1x-aware. For example, suppose that
you have configured a port on the switch for 802.1x authentication operation.
If you then connect an 802.1x-aware client (supplicant) to the port and
attempt to log on:
1. When the switch detects the client on the port, it blocks access to the LAN
from that port.
2. The switch responds with an identity request.
3. The client responds with a user name that uniquely defines this request
for the client.
4. The switch responds in one of the following ways:
• If 802.1x (port-access) on the switch is configured for RADIUS
authentication, the switch then forwards the request to a RADIUS
server.
i. The server responds with an access challenge which the switch
forwards to the client.
ii. The client then provides identifying credentials (such as a user
certificate), which the switch forwards to the RADIUS server.
iii. The RADIUS server then checks the credentials provided by the
client.
iv. If the client is successfully authenticated and authorzed to con-
nect to the network, then the server notifies the switch to allow
access to the client. Otherwise, access is denied and the port
remains blocked.
• If 802.1x (port-access) on the switch is configured for local authenti-
cation, then:
i. The switch compares the client’s credentials with the username
and password configured in the switch (Operator or Manager
level).
ii. If the client is successfully authenticated and authorzed to con-
nect to the network, then the switch allows access to the client.
Otherwise, access is denied and the port remains blocked.
!FishSecurity.book Page 4 Thursday, October 10, 2002 9:19 PM
