7-10
Using Authorized IP Managers
Building IP Masks
Configuring Multiple Stations Per Authorized Manager
IP Entry
The mask determines whether the IP address of a station on the network meets
the criteria you specify. That is, for a given Authorized Manager entry, the
switch applies the IP mask to the IP address you specify to determine a range
of authorized IP addresses for management access. As described above, that
range can be as small as one IP address (if 255 is set for all octets in the mask),
or can include multiple IP addresses (if one or more octets in the mask are set
to less than 255).
If a bit in an octet of the mask is “on” (set to 1), then the corresponding bit in
the IP address of a potentially authorized station must match the same bit in
the IP address you entered in the Authorized Manager IP list. Conversely, if a
bit in an octet of the mask is “off” (set to 0), then the corresponding bit in the
IP address of a potentially authorized station on the network does not have to
match its counterpart in the IP address you entered in the Authorized Manager
IP list. Thus, in the example shown above, a “255” in an IP Mask octet (all bits
in the octet are “on”) means only one value is allowed for that octet—the value
you specify in the corresponding octet of the Authorized Manager IP list. A “0”
(all bits in the octet are “off”) means that any value from 0 to 255 is allowed
in the corresponding octet in the IP address of an authorized station. You can
also specify a series of values that are a subset of the 0-255 range by using a
value that is greater than 0, but less than 255.
