2-2
TACACS+ Authentication
Overview
Overview
TACACS+ authentication enables you to use a central server to allow or deny
access to the Switch 2650 and 6108 (and other TACACS-aware devices) in your
network. This means that you can use a central database to create multiple
unique username/password sets with associated privilege levels for use by
individuals who have reason to access the switch from either the switch’s
console port (local access) or Telnet (remote access).
Figure 2-1. Example of TACACS+ Operation
TACACS+ in the Switch 2650 and 6108 manages authentication of logon
attempts through either the Console port or Telnet. TACACS+ uses an authen-
tication hierarchy consisting of (1) remote passwords assigned in a TACACS+
Feature Default Menu CLI Web
view the switch’s authentication configuration n/a — page
2-10
—
view the switch’s TACACS+ server contact
configuration
n/a — page
2-10
—
configure the switch’s authentication methods disabled — page
2-11
—
configure the switch to contact TACACS+ server(s) disabled — page
2-15
—
B
Switch 2650 or 6108
Configured for
TACACS+ Operation
Terminal "A" Directly
Accessing the Switch
Via Switch’s Console
Port
Terminal "B" Remotely Accessing The Switch Via Telnet
A
Primary
TACACS+
Server
The switch passes the login
requests from terminals A and B
to the TACACS+ server for
authentication. The TACACS+
server determines whether to
allow access to the switch and
what privilege level to allow for
a given access request.
Access Request A1 - A4 : Path for Request from
Terminal A (Through Console Port)
TACACS Server B1 - B4: Path for Request from
Response Terminal B (Through Telnet)
B1
A2 or
B2
A3 or
B3
B4
A1
A4
!FishSecurity.book Page 2 Thursday, October 10, 2002 9:19 PM
