HP ProCurve Switch 2650 User Manual

7-1
7
Using Authorized IP Managers
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Defining Authorized Management Stations . . . . . . . . . . . . . . . . . . . . . 7-4
Overview of IP Mask Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Menu: Viewing and Configuring IP Authorized Managers . . . . . . . . . . 7-5
CLI: Viewing and Configuring Authorized IP Managers . . . . . . . . . . . . 7-6
Listing the Switch’s Current Authorized IP Manager(s) . . . . . . . . 7-6
Configuring IP Authorized Managers for the Switch . . . . . . . . . . 7-7
Web: Configuring IP Authorized Managers . . . . . . . . . . . . . . . . . . . . . . 7-8
Building IP Masks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Configuring One Station Per Authorized Manager IP Entry . . . . . . . . 7-9
Configuring Multiple Stations Per Authorized Manager IP Entry . . . 7-10
Additional Examples for Authorizing Multiple Stations . . . . . . . . . . 7-12
Operating and Troubleshooting Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
!FishSecurity.book Page 1 Thursday, October 10, 2002 9:19 PM

HP ProCurve Switch 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	Layer 2
Form Factor	Rack-mountable
Flash Memory	8 MB
Jumbo Frame Support	Yes
Power Supply	Internal
Management	Web, CLI, SNMP
Features	VLAN support, IGMP snooping, QoS
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	15% to 95% (non-condensing)
Ports	48 x 10/100
MAC Address Table Size	8, 000 entries
