HP ProCurve Switch 2650 User Manual

3-28
RADIUS Authentication and Accounting
Changing RADIUS-Server Access Order
To exchange the positions of the addresses so that the server at 10.10.10.003
will be the first choice and the server at 10.10.10.001 will be the last, you would
do the following:
1. Delete 10.10.10.003 from the list. This opens the third (lowest) position in
the list.
2. Delete 10.10.10.001 from the list. This opens the first (highest) position in
the list.
3. Re-enter 10.10.10.003. Because the switch places a newly entered address
in the highest-available position, this address becomes first in the list.
4. Re-enter 10.10.10.001. Because the only position open is the third position,
this address becomes last in the list.
Figure 3-18. Example of New RADIUS Server Search Order
Removes the "003" and "001" addresses from the
RADIUS server list.
Inserts the "003" address in the first position in
the RADIUS server list, and inserts the "001"
addresss in the last position in the list.
Shows the new order in which the switch
searches for a RADIUS server.
!FishSecurity.book Page 28 Thursday, October 10, 2002 9:19 PM

HP ProCurve Switch 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	Layer 2
Form Factor	Rack-mountable
Flash Memory	8 MB
Jumbo Frame Support	Yes
Power Supply	Internal
Management	Web, CLI, SNMP
Features	VLAN support, IGMP snooping, QoS
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	15% to 95% (non-condensing)
Ports	48 x 10/100
MAC Address Table Size	8, 000 entries
