Removal and replacement procedures 60
5.
Open the processor retaining latch and the processor socket retaining bracket.
6. Carefully lift the processor straight out of the socket.
To replace the processor:
1. Install the processor.
CAUTION: To avoid damage to the processor:
• Handle the processor only by the edges.
• Do not touch the bottom of the processor, especially the contact area.
CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED. To
avoid damage to the system board:
• Do not touch the processor socket contacts.
• Do not tilt or slide the processor when lowering the processor into the socket.
2. Close the processor retaining bracket and the processor retaining latch.
