59
Item Descri
tion
connection.
Fin: Finish. This indicates there is no more data from the sender. This marks a normal
closing of the session between the sender and receiver.
Source IP Address
If selected, enables matching the source port IP address to which packets are addressed
to the rule, according to a wildcard mask. The field value is either user defined or Any. If
Any is selected, accepts any source IP address and disables wildcard mask filtering.
Dest IP Address
If selected, enables matching the destination port IP address to which packets are
addressed to the rule, according to a wildcard mask. The field value is either user defined
or Any. If Any is selected, accepts any destination IP address and disables wildcard mask
filtering.
Match DSCP If selected, matches the packet DSCP value to the ACL.
Match IP
Precedence
If selected, Matches the packet IP Precedence value to the ACL.
Action
Defines the ACL forwarding action. In addition, a trap can be sent to the network
administrator, or packet is assigned rate limiting restrictions for forwarding. The options
are as follows:
Permit: Forwards packets which meet the ACL criteria.
Deny: Drops packets which meet the ACL criteria.
To create a new IP-based ACL:
1. Select Create ACL.
2. Enter the name of the new ACL.
3. Click Create.
To define a new IP-based ACL rule:
1. Select Selection ACL.
2. Select the ACL from the list.
3. Define the fields for the new ACL rule.
4. Click Apply.
Modifying IP Based ACL
The IP Based ACL Modify Page allows the network administrator to modify IP Based ACL rules.
Click Device ACL IP Based ACL Modify. The IP Based ACL Modify Page opens.
